Product Details:
|
| Place Of Origin: | Beijing, China | Brand Name: | SPARK |
|---|---|---|---|
| Model Number: | Ni-Cr | Type: | Bare |
| Application: | Heating | Conductor Material: | Ni-Cr |
| Conductor Type: | Solid | Insulation Material: | Rubber |
| Product Name: | Spark | Surface: | Black Annealed Dead Soft |
| Standard: | GB/T343 Standards | Tensile Strength: | 700-900 |
| Color: | Bright White | Size: | Width:0.5-4.5mm |
| Size: | Ribbon Thickness0.08-0.4mm | Certification: | ISO9001 |
| Package: | Wooden Case | Material: | Ni-Cr |
Resistance heating alloys are one of the main products of our company, they are classified into two categories: Fe-Cr-Al alloys and Ni-Cr alloys. These alloys are widely used in making industrial heating equipments and domestic heating appliances. All resistance heating alloys manufactured by our company are distinguished by uniform composition, high resistivity, accurate dimension, long operating life and good processability. Consumers can select the suitable grade according to different requirements.
Properties and Applications
|
Steel grades |
Max.continuous operating temperature℃ |
Tensile strength N/mm2 |
Elongation at rupture(approx.)% |
Electrical resistivity μ·Ω·m |
|
Cr15Ni60 |
1150℃ |
700-900 |
>25 |
1.07-1.20 |
|
Cr20Ni30 |
1050℃ |
700-900 |
>25 |
0.99-1.11 |
|
Cr20Ni35(N40) |
1100℃ |
700-900 |
>25 |
0.99-1.11 |
|
Cr20Ni80 |
1200℃ |
700-900 |
>25 |
1.04-1.19 |
|
Cr30Ni70 |
1250℃ |
700-900 |
>25 |
1.13-1.25 |
Size range
|
Wire diameter |
Ø0.05—8.0mm |
|
Ribbon |
Thickness 0.08—0.4mm |
|
Width 0.5—4.5mm |
|
|
Strip |
Thickness 0.5—2.5mm |
|
Width 5.0—48.0mm |
As for the costs and shipping period information, please contact us via telephone, mail or online trade manager.
