Product Details:
Place of Origin: Beijing, China
Brand Name: SPARK, SPARK
Model Number: Cr15Ni60
Payment & Shipping Terms:
Minimum Order Quantity: 100.0 Kilograms
Price: $25.00(>=100 Kilograms)
Packaging Details: We use plastic film packaging to package the axle wire, and the outer packaging of the shaft wire uses wooden pallet. The coils are packed in closed wooden cases.
Supply Ability: 1000 Kilogram/Kilograms per Week

Heater Nicr Cr15ni60 Nicr Alloy Electrothermal Ribbon Aluminum Fe-Cr-Al Alloy

Description
Place Of Origin: Beijing, China Brand Name: SPARK
Model Number: Cr15Ni60 Type: Bare
Application: Heating Conductor Material: Aluminum
Conductor Type: Solid Insulation Material: Rubber
Colors: Golden/bright/blue Product Name: Fe-Cr-Al Alloy Wire
Standard: GB/T 1234-2012 Size: 0.03-10.00
Packing: Wooden Box Elongation(≥%): 15-25
Brand Name:: SPARK Wire Diameter: 0.05-80mm
Ribbon Thickness: 0.08-0.4mm Ribbon Width: 0.5-4.5mm

Product Description



Ni-Cr electrothermal alloy has high temperature strength. It has good toughness and does not easily deform. Its grain structure is not easily changed. The plasticity is better than Fe-Cr-Al alloys. No brittleness after high temperature cooling, long service life, its easy to process and welding, but the service temperature is lower than Fe-Cr-Al alloy. Ni-Cr electrothermal alloys are one of the main products of our company. All resistance heating alloys manufactured by our company are distinguished by uniform composition, high resistivity, stable quality, accurate dimension, long operating life and good processability. Consumers can select the suitable grade according to different requirements.



Steel grades and Chemical composition(GB/T1234-1995)

Steel grades

Chemical composition(%)

C

Si

Cr

Ni

Fe

Cr15Ni60

≤0.08

0.75-1.6

15-18

55-61

-

Cr20Ni30

≤0.08

1-2

18-21

30-34

-

Cr20Ni35(N40)

≤0.08

1-3

18-21

34-37

-

Cr20Ni80

≤0.08

0.75-1.6

20-23

remain

≤1

Cr30Ni70

≤0.08

0.75-1.6

28-31

remain

≤1











Properties and Applications

Steel grades

Max.continuous operating temperature

Tensile strength N/mm2

Elongation at rupture(approx.)%

Electrical resistivity μ·Ω·m

Cr15Ni60

1150℃

700-900

>25

1.07-1.20

Cr20Ni30

1050℃

700-900

>25

0.99-1.11

Cr20Ni35(N40)

1100℃

700-900

>25

0.99-1.11

Cr20Ni80

1200℃

700-900

>25

1.04-1.19

Cr30Ni70

1250℃

700-900

>25

1.13-1.25



Size range

Wire diameter

Ø0.05—8.0mm

Ribbon

Thickness 0.08—0.4mm

Width 0.5—4.5mm

Strip

Thickness 0.5—2.5mm

Width 5.0—48.0mm
